PROLiNK CAT6 UTP Cable 23AWG Gray For Full Box Sales
- Model: CAT6
- 4-pair cable
- 23 AWG conductor
- Quality verified by Fluke test
- Guaranteed long PoE transmission distance
Size Guides
SIZE GUIDE
JEANS
| SIZE | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| BUST | 88 | 89 | 90 | 91 | 92 | 93 |
| WAIST | 55 | 56 | 58 | 59 | 62 | 65 |
| HIPS | 90 | 92 | 94 | 95 | 96 | 98 |
T-SHIRTS
| SIZE | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| BUST | 60 | 62 | 65 | 66 | 68 | 69 |
| WAIST | 50 | 55 | 58 | 62 | 65 | 66 |
| HIPS | 80 | 82 | 85 | 86 | 88 | 89 |
Delivery and return
Delivery and return
Shipping Information
Shipping Information
Composition and care
Composition and care
Description
| Connection Class | ||
| Standard | TIA/EIA-568A/568B & ISO 11801 | |
| Shielding Connector | UTP | |
| Connector Type | 23 AWG (4 pairs) | |
| Category Connector | Cat6 | |
| Physical Specs | ||
| Dimensions | 390 x 390 x 235mm (L x W x H) Easy-pull boxes/Cable length of 305M |
|
| Color | A White-Blue Stripe and a Blue B White-Orange Stripe and Orange C White-Green Stripe and Green D White-Brown Stripe and Brown |
|
| Cable Details | ||
| Conductor | Material: CCA (Copper content: 35%) Conductor Diameter: 0.56±0.02mm Conductor Resistance MAX 18Ω/100m at 20°C Mutual Capacitance: MAX 5600pf/100M Resistance Unbalance: MAX 5% Resistance Unbalance: MAX 300pf/100M |
|
| Insulation | Insulation: High-Density Polyethylene Insulation Diameter: 0.93±0.02mm Insulation Nominal Wall Thickness: 0.2mm Insulation Resistance: MIN 150MΩ/KM |
|
| Twisting | 2 Insulated conductors twisted together | |
| Technical Detail | ||
| Cable Designation | Cable Diameter: 5.6±0.15mm Printing: Each meter printed with a sequential length counter Jacket Nominal Wall Thickness: 0.7±0.01mm |
|
| Outer Diameter | Cable Diameter: 5.6±0.15mm | |
| Weight | 9.67kg/roll (Cable Only) 10.53kg (With Box) |
|
| Temperature ange | 75℃ | |
